HONDA CRF1000L Africa Twin 18/19 Cruise Kit – Veridian Cruise

Compatibility

• 2018 2019 CRF1000L Africa Twin (Manual or DCT)

Triple Button Switch

A 3 button switch for controlling the cruise functions is included. Fully watertight and durable. Mounts directly to standard 22mm handlebars with a fully opening bracket. This option provides 3 buttons.

• Resume Increase
• Cancel
• SET Decrease

LED lights and other upgradecompatibility

This kit is not compatible with motiondeceleration based brake flashers.

This kit is compatible with brake flashers triggered by the pedallever.

This kit is compatible with aftermarket LED kits.

This kit is compatible with stock and aftermarket heated grips.

Cruise Stop Conditions

We know its paramount on motorbikes to quickly kill the cruise control in as many situations as possible. Our module will disengage cruise control for any one of the following conditions

• Engine RPM signal exceeds 6500RPM
• Front or Rear brake depressed
• Throttle grip exceed cruise control by 5%
• Any one of the required CANBUS packets are not updated within 1000 milliseconds

Configuration

The module has a weather tight USB-C connector for changing various settings such as speed increment size, PID gain, and throttle limits.

Diagnostic Port

This kit uses the diagnostic port of your bike. If you need diagnostics you can simple unplug our module and the kit will still run in bypass mode.

Install Difficulty

To install this kit you must get access to the fuel tank and airbox. Knowledge of getting to your air filter is required. About 1 2 hours install time with proper tools. T-harness will override the throttle signals and diagnostic connector will collect important speed data. This kit also requires a single T-Tap connection into the brake wire
